Benefits of our converters
- Sensorless control for highly dynamic speed adjustment
- Minimal losses in the converter, turbo compressor and motor
- Highest power density
- Gas bearing diagnostics and fuel cell functions
- Custom adaptations possible
All our converters allow sensorless control of turbo compressors and motors up to the highest speeds. The solution from one single source guarantees optimal compatibility of the converters and the turbo compressors and motors, thus minimizing losses in the turbo compressor or motor and ensuring high converter efficiency and a smooth startup process.
Matching the modulation and control to our own motors and turbo compressors, your permanent-magnet synchronous machine (PMSM) or your brushless DC motor (BLDC) guarantees maximum performance in the converter and minimal losses in the motor, especially in the rotor. The proprietary sensorless control strategies enable speed control without encoders or Hall sensors. The converter software makes it possible to diagnose the compressor and monitor the condition of the gas bearing as well as providing various application-specific functions, such as startup procedures for fuel cell systems.
|Type||Output power||Control range||Input voltage||Output voltage||Weight||Datasheet||.step File|
|CC-75-500||500 W||0 - 1,000,000 rpm||24 - 75 VDC||0 - 0.95 Uin||1 kg|
|CC-100-1000||1,000 W||0 - 500,000 rpm||24 - 100 VDC||0 - 0.93 Uin||280 g|
|CC-120-1000||1,000 W||0 - 500,000 rpm||40 - 120 VDC||0 - 100 V||1.4 kg|
|CC-230-3500||3,500W||0 - 500,000 rpm||110 - 230 VAC||0 - 360 V||4.5 kg||Celeroton_Converter_CC-230-3500-step-file|
|CC-550-7500||7,5 kW||0 - 300,000 rpm||100 - 550 VDC||0 - 0.95 Uin|
max 460 V
|CC-400-12000||12 kW||0 - 180,000 rpm||200 - 420 VDC||0 - 0.95 Uin||12 kg|
|CC-410-2500||2,500 W||0 - 300,000 rpm||360 - 410 VDC||0 - 0.95 Uin||3.5 kg|
|CC-2000||8 kW||0 - 300,000 rpm||100 - 550 VDC||0 - 0.95 UHV|
max. 460 V
|CC-3000||21 kW||0 -130,000 rpm||120 - 500 VDC||0 - 650 V||15.8 kg|
|CC-3001||21 kW||0 -130,000 rpm||400 - 800 VDC||0 - 650 V||15.8 kg|
With all of our converter products we provide for free our user-friendly control software “CelerotonPilot”. CelerotonPilot is currently available for Windows® 10, 8 and 7 operating systems. You can download the software via this link.
